Description
Core Printing Performance
- Multicolor Printing: Supports 4- or 8-color printing
- Printing Volume: 250 × 250 × 260 mm³
- Supporting Filaments: PLA / PETG / TPU (TPU is not compatible with the ACE Pro)
- Printing Speed: Recommended 300 mm/s, Maximum 600 mm/s
- Acceleration: Recommended 10,000 mm/s², Maximum 20,000 mm/s²
Nozzle Specs
- Max Temperature: 300°C
- Diameter: Standard 0.4 mm (expandable to 0.6 / 0.8 mm)
Hotbed Specs
- Max Temperature: 110°C
- Material: PEI spring steel build plate
System & Structural Design
- Firmware Solution: Kobra OS
- Construction: Gantry system
- Extrusion Type: Direct drive (short distance extrusion)
- Machine Leveling: LeviQ 3.0 auto-leveling, Z-offset
- Pressure Advance / Flow Calibration: –
- Power Loss Resume: Supported
- Filament Detection & Auto Resume: Supported
- Filament Entanglement Detection: Supported
- AI Spaghetti Detection: Supported
- Object-Skip & Area Leveling: Supported
Control & Print Methods
- Via printer, slicing software, Anycubic app, USB (print only)
User Experience & Features
- Touchscreen: 4.3-inch capacitive touch screen
- Noise: –
- Video Monitoring: Optional 720p HD camera
- Multilingual Support: EN / CN / DE / FR / IT / ES / RU / JP
- Machine Weight: Kobra 3 V2 – 9.2 kg, ACE Pro – 4.6 kg
- Package Weight: Kobra 3 – 12 kg, ACE Pro – 5.7 kg
- Machine Dimensions: Kobra 3 – 452.9 × 504.7 × 483 mm³, ACE Pro – 365.94 × 282.84 × 234.5 mm³
- Packaging Dimensions: 500 × 500 × 550 mm³
