Large build volume
Photon Mono 2 has the same size as its predecessor, the Photon Mono 4K. Nevertheless, this resin printer convinces with a larger build volume of 143 x 89 x 165 mm and a maximum print volume of 2.09 litres! So you can tackle incredibly creative projects while saving space!
4K+ Monochrome LCD Screen
The Photon Mono 2 uses a 6.6-inch monochrome 4K+ LCD screen with a resolution of 4096 x 2560 pixels. With better resolution, even highly detailed prints can become the norm!
You can print up to over 2000 hours with it!
Oversized anti-scratch film
The scratch-resistant screen protector prevents scratches and other unforeseen “accidents” when the resin leaks. With a light transmission of up to 95%, the screen protector not only protects the display but also ensures outstanding printing accuracy at the same time.
Optimised LighTurbo matrix for even more vivid details
The LighTurbo matrix has been optimised to make the parallel light source even more stable and uniform. This effectively reduces layer lines on the one hand and completely eliminates grid lines on the other. Nothing stands in the way of vivid details and fine, smooth surfaces!
Laser engraved platform
Photon Mono 2 is equipped with a laser-engraved aluminium alloy platform. This features outstanding flatness, which greatly improves model adhesion and therefore printing success rate. The laser-engraved platform prevents the model from falling off or warping.
Anycubic Photon Workshop 3.0 Slicer
The new version of the slicer has been completed and optimised with some improved and updated features. Not only is the new user interface much easier to use – the slicing process has also been made a whole lot easier.
Specifications:
- Printing Volume: 2.09L/73.5oz.
- Printing Dimensions: 165x89x143mm(HWD)
- Printing Speed: ≤50mm/hr
- Machine Leveling: 4-point manual leveling
- Light Source: Parallel matrix upgrade light source
- Z Axis: Single liner with 10 μm accuracy
- Resin Vat: Unibody design with scale lines
- Exposure Screen
- 6.6″ monochrome
- 4,096 x 2,560px
- 2,000 hours lifespan
- Build Platform: Laser engraving aluminium alloy
- Control Panel: 2.8″ TFT touch-control
- Removable Cover: Effectively blocks UV radiation
- Screen Protector: Replaceable anti-scratch film
- Power Supply: 48W rated power
- Data Input: USB Type-A 2.0
