Description
Core Printing Performance
- Printing Volume: 223 × 126 × 230 mm³ (6.5 L)
- Printing Speed: Max speed ≤ 90 mm/h; Standard resin (0.1 mm): ≤ 90 mm/h; High-speed resin (0.1 mm): ≤ 150 mm/h
- Layer Height Range: 0.01 – 0.15 mm
- X/Y Axis Resolution: 16.8 × 24.8 μm
- Light Source: COB light source + Fresnel lens + light uniformity algorithm
- Light Intensity: 4500 ± 10% μW/cm²
- Material Compatibility: High-speed, water-washable, standard, ABS-like, and plant-based resins
System & Mechanical Design
- Build Platform: Laser-engraved build plate
- Z-axis: Dual linear rails with 10 μm precision
- Release Film: Improved ACF film
- Resin Vat: ≤ 1 L
- Machine Leveling: Leveling-free
- Power Loss Resume: Not supported
- Power Supply: 135 W
- Protection Film: Replaceable scratch-resistant film
- Resin Auto-fill Unit: Not supported
- Dynamic Temperature Control Resin Vat: Not supported
Connectivity & Software
- Slicing Software: Photon Workshop, Chitubox, Lychee Slicer (scheduled)
- File Transfer: USB / WiFi / LAN (scheduled)
User Experience & Features
- Hinged Cover: –
- Operating Screen: 4.3″ touch-control
- Air Purifier: Optional accessory
- LCD Screen: 10.1-inch monochrome LCD, 14K resolution
- Anycubic App: Supported
- Multilingual Support: EN / CN / DE / FR / IT / ES / RU / JP
- Machine Weight: 12 kg
- Package Weight: 13 kg
- Product Dimensions: 312 × 315 × 520 mm³
- Packaging Dimensions: 620 × 395 × 395 mm³
