Description
| Specifications | Range | Accuracy | ||
| DC Voltage | 600.0mV/6.000V/60.00V/600.0V/1000V | ±(0.5%+3) | ||
| AC Voltage | 600.0mV/6.000V/60.00V/600.0V/750V | ±(1.0%+3) | ||
| DC Current | 600.0μA/6000μA | ±(1.2%+3) | ||
| AC Current | 600.0μA/6000μA | ±(1.5%+3) | ||
| 600.0A/1000A | ±(2.0%+30) | |||
| Resistance | 600.0Ω/6.000kΩ/60.00kΩ/600.0kΩ/6.000MΩ | ±(0.5%+3) | ||
| 60.00MΩ | ±(1.5%+3) | |||
| Capacitance | 9.999nF | ±(5.0%+20) | ||
| 99.99nF/999.9nF/9.999μF/99.99μF/999.9μF | ±(2.0%+5) | |||
| 9.999mF | ±(5.0%+5) | |||
| Frequency | 99.99Hz/999.9Hz/9.999kHz/99.99kHz/
999.9kHz/9.999MHz |
±(0.1%+2) | ||
| Duty Cycle | 1%-99% | ±(0.1%+2) | ||
| Temperature | -20℃~1000℃/-4℉~1832℉ | ±(2.5%+5) | ||
| Diode/Continuity | ●/● | |||
| Features | ||||
| Auto/Manual ranging | True RMS | Data hold | ||
| Backlight | Low battery alert | Auto power off | ||
